FFD224-6
Full Force Series AGM Batteries
Display Units:
Imperial
Metric
BCI Group Size
GC2
Capacity @ C20
224 Ah
Reserve Capacity @ 25A
441 minutes
CCA
900 Amps
Dimensions
10.24 x 7.09 x 10.71 inches
Weight
67.3 lbs.
Electrical Specifications
Nominal Voltage
6-Volt
Capacity @ C100
246 Ah
Capacity @ C20
224 Ah
Capacity @ C10
210 Ah
Capacity @ C5
179 Ah
Reserve Capacity @ 25A
441 minutes
Reserve Capacity @ 75A
113 minutes
CCA
900 Amps
CA / MCA
1080 Amps
Internal Resistance
1.6 mΩ
Mechanical Specifications
BCI Group Size
GC2
Terminal Type
M8 + TP28
Length
10.24 inches
Width
7.09 inches
Height (case only)
9.69 inches
Total Height (with terminals)
10.71 inches
Weight
67.3 lbs.
Case Type
ABS Plastic
